Xy-1a Hydraulic Small Rotary Drilling Rig Machine For 150 Meters Depth

Name: Xy1a Hydraulic Small Rotary Drilling Rig Machine For 150 Meters Depth
Brand: ShiTan
Price: 1 USD

Wholesale Xy-1a Hydraulic Small Rotary Drilling Rig Machine For 150 Meters Depth from china suppliers

Brand Name : ShiTan

Model Number : XY-1A

Certification : ISO9001

Place of Origin : China

MOQ : Negotiation

Price : Negotiation

Payment Terms : T/T, Western Union

Delivery Time : Within 7ays

Packaging Details : Wooden box

Product Name : XY-1A Small Hydraulic Drilling Machine 150 Meters Detph Crawler Mounted Drilling Rig

Type : hydraulic crawler drilling rig

Color : Red Yellow

Feature : High Drilling Efficiency

Usage : Water Well

Application : Soil Sampling,water well drilling

Power Type : Diesel

Drilling Depth : 150 Meters

Hole Diameter : 150mm

Warranty : 12 months

OEM : acceptable

Mud Pump : BW 160

Condition : New

Contact Now

XY-1A Small Hydraulic Drilling Machine 150 Meters Detph Crawler Mounted Drilling Rig

XY-1A Crawler Mounted Drilling Rig Information

XY-1 A drilling rig is a light drill for shallow hole with a hydraulic feeding. It is efficient and convenient, designed by our company to meet the requirements of modern geological and engineering operations, and the feedback of our customers all over the world has been positive.

XY-1A Crawler Mounted Drilling Rig Tech Data

Drill		Swivel Head
Drilling depth	Max.150m	Spindle speed	1010,790,470,295,140(r/min)
Hole diameter	Max.150m	Spindle stroke	450kmm
Drill rod diameter	42mm	Spindle pull-down	Max.15KN
Angle range	90-75	Spindle lifting capacity	Max. 25KN
Oil pump		Water pump
Model	YBC-12/125	Model	Horizontal reciprocating single-acting piston pump
Rated pressure	12.5Mpa	Working pressure	Max. 1.25Mpa
Flow speed	8ml/r
Rated speed	1500r/min
Hoist		Power(diesel)
Max. lifting capacity	15KN	Model(diesel engine	ZS1105
Hoisting drum revolution	121,76,36(r/min)	Rated power	12.1KW
Drum diameter	140mm	Rated speed	2200r/m
WEIGHT	AROUND 600KG
SIZE	16209701560mm

XY-1A Crawler Mounted Drilling Rig Advantages

XY-1A High Speed Core Drilling Rig
a. five gears, and the highest speed can reach 1045r/min, improving drill efficiency
b. 53 x 59 drilling rod adopted, high rigidity and strong delivery torque.
c. the machine is equipped with national patent technology---taper clutch, with charactristics of strong transmission troque, easy operation and free maintenance.
d. for the winch, we use large module planetary gear and add supporting frame, greatly increasing hoisting and braking ability of the winch.
e. Vertical spidle are fixed by four groups of bearings to ensure that the rotary machine is rigid enough for gravel layer and other complex geoloical conditions.

Why us for XY-1A Crawler Mounted Drilling Rig

1.Top-notch technical team
2.Strict quality management
3.Advanced and first-class equipment
4.Professional experience of 20 years
5.Comprehensive international standard

Jinzhou Shitan Machinery Equipment Co., Ltd. Main Products：

Pneumatic Drilling Rig / Air Drilling Rig（ST-180, ST-200, ST-260, ST-300, ST-350, ST-400, ST450, ST-450, ST-500, ST-600, ST-800 and other Pneumatic water well drilling Rigs.）, Crawler Water Well Drilling Rig / Trailer Mounted Drilling Rig / Water Well Drilling Rig / Hydraulic Borewell Machine / Hard Rock Drilling Equipment / Diamond Core Drill Rig / Geological Drilling Rig / Soil Testing Drilling Rig / Portable Water Well Drilling Rig（ST-30，ST-50，XY-1A, XY-1B, XY-2, XY-2B, GK180, GK200, GY150, GY200 and 30 impact drill rig, ZLJ series tunnel drilling rig and other geological drilling machines）Crawler Track Undercarriage, Drilling Mud Pump（BW150,BW160,BW200,BW250,BW850 series Drilling mud pumps）, Drilling Air Compressor, Water Well Drill Bits（PDC Drill Bit， Tricone Bit， DTH Button Bit）, Water Well Drill Pipe, Drilling Rig Spare Parts( drilling rods , drilling rods joint , casing pipe, casing coupling, core tube, core tube coupling, lifters, automatic drop hammer, sampler, SPT tool, wrench fork, pad fork, lock joint), Track Transporter

OEM / ODM can accept. Good quality, professional after-sales service, welcome to order
